The reference system for recoverable voided slabs.
Horizontal formwork system with recoverable voids for the construction of voided slabs. Ideal for non-residential building projects in industrial and commercial use.
Impact on formwork floor
1,46
props/m2
For standard slabs
Impact on braced floor
0,6
props/m2
For standard slabs
Dimensions between props
Longitudinal
1,00
m
Transversal
0,80
m
On the formwork floor (standard slab)
Number of elements
4
elements
Straps, strap holders, crosspieces, and plastic void formers
Number of void ribs:
7
(N12, N14, N15, N16, N17, N18, N20)
Void former edges:
5
(Available in the following heights: 20cm, 25cm, 30cm, 35cm, 40cm)
Formwork surface
Plastic, wood
Material
Galvanized steel, plastic
Main advantages
Maximum performance system
Maximum performance system
Quick assembly
and disassembly
thanks to a proprietary system for each rib.
Specific elements
for each void rib
avoiding the additional use of additional pieces.
Maximum variety of
typologies
due to its thickness and high elastic limit of steel.
Very resistant PVC
void former
that does not suffer deformations
Completely secure system
thanks to the non-slip fixing pins of the buckets and board.
